Small Timber Frame Shabin

Here are some pictures of our cabin that we built this past fall. I bought the land 8 years ago and i'm just now finding the time and money to make this dream a reality. We pre-cut and assembled the entire frame in the shop first.
I had my local shed builder build and deliver the 13'-5" x 28' insulated floor to my shop.
We then reassembled the frame on the platform. And sheathed it with 1 x 12 t&g pine. We also added 1" rigid foam insulation on top of the sheathing. The roof will get two layers of 1" insulation board with the seams staggered.
One week after the floor was delivered to my shop, our cabin was being delivered to our property in Sullivan County. After a couple of hours we had the trusses set and ready for sheathing.
We busted our butts and got it weather tight in one weekend.
My cousin and I went up this past weekend and installed the windows and doors.
The living/bedroom.
Kitchen is on the left, bathroom on the right will be enclosed by more 1x12 pine and include a composting toilet. The loft will get a small window.
The next trip will include installing the composting toilet, wood stove and painting the floor. You might not think that 1" of insulation on the walls and 2" on the roof would be enough insulation to keep it warm, but we have been heating it with a big buddy propane heater and it gets too hot to sleep in the loft. The nice thing about this method of construction is there's no fiberglass or drywall and very little interior trim to deal with.
McGillicutty is offline
Sponsored Links
Advertisement

post #2 of 29 (permalink) Old 12-06-2013, 11:34 PM
Diehard Outdoorsman

Join Date: Aug 2004
Location: Washington PA
Posts: 4,887
Back To Top
Re: Small Timber Frame Shabin

Very very nice!!!

The United States of America has the greatest people on earth.
Deer archer is offline
post #3 of 29 (permalink) Old 12-06-2013, 11:41 PM
Diehard Outdoorsman

blitzinstripes's Avatar

Join Date: Jun 2010
Location: SC PA
Posts: 3,064
Back To Top
Re: Small Timber Frame Shabin

Cool! Thanks for sharing!
blitzinstripes is offline
Sponsored Links
Advertisement

post #4 of 29 (permalink) Old 12-06-2013, 11:44 PM
Sage

Join Date: Feb 2002
Location: Townsend, DE
Posts: 52,307
Back To Top
Re: Small Timber Frame Shabin

Looking good can hardly wait to get back to carpentry work,, keep us posted, every time you do a detail if you can , this is great.....
RonM is offline
post #5 of 29 (permalink) Old 12-06-2013, 11:51 PM
Frequent Contributor

Join Date: Dec 2011
Location: Lebanon co
Posts: 666
Back To Top
Re: Small Timber Frame Shabin

Very nice!

The Second Ammendment...
Its kind of a big deal.
Papsattic is offline
post #6 of 29 (permalink) Old 12-07-2013, 12:23 AM
Diehard Outdoorsman

Join Date: Dec 2008
Location: wyoming county,pa.
Posts: 3,370
Back To Top
Re: Small Timber Frame Shabin

Looks Great
Claybird John is offline
post #7 of 29 (permalink) Old 12-07-2013, 12:24 AM
Senior Member

Join Date: Oct 2001
Location: lancaster
Posts: 12,031
Back To Top
Re: Small Timber Frame Shabin

Always been a fan of post and beam. looks good.
zimmerstutzen is offline
post #8 of 29 (permalink) Old 12-07-2013, 02:55 AM
Regular Member

Join Date: Nov 2009
Location: Chambersburg, PA
Posts: 1,754
Back To Top
Re: Small Timber Frame Shabin

Nice looking cabin. Anxious to see the exterior finished.

Faith sees the invisible, believes the incredible and receives the impossible!
Acorn20 is offline
post #9 of 29 (permalink) Old 12-07-2013, 10:34 AM
The Man

rrroae's Avatar

Join Date: Apr 2006
Location: pa,crawford county
Posts: 6,030
Back To Top
Re: Small Timber Frame Shabin

Love seeing these threads!


Great job bud and hope you keep us updated.

If Tyranny and Oppression come to this land, it will be in the guise of fighting a foreign enemy JM
rrroae is offline
post #10 of 29 (permalink) Old 12-07-2013, 01:24 PM
Moderator

Samuel's Avatar

Join Date: Feb 2001
Location: Mountains
Posts: 2,467
Back To Top
Re: Small Timber Frame Shabin

awesome!

"You meet a better class of people in the dark."
-LP

Ever get lonely? Remember the NSA is right there with you!
Samuel is offline
